Coselium · Building automation
Controllers, remote I/O and software for building automation.
Coselium controllers run the application inside the device with Sedona, and connect to the supervisory system over BACnet, Modbus and MQTT, and to Niagara N4 with the cosel modules. Hardware, firmware and programming tool are developed by one team.
FiOC-4040-point Sedona controller that runs the application on the device FiOC-40 · Controller
Control logic and 40 I/O points in one DIN-rail unit.
The application runs on the device, so the panel keeps its logic even when the supervisory link drops. It is programmed live with Coselium Workbench or Niagara N4.
FiO-40 · Remote I/O
Adding points without programming.
FiO-40 comes with a ready Modbus and BACnet point list and is defined in an existing BMS without programming. When needed, a licence also lets it work as a Modbus gateway or BACnet router.
Coselium Workbench · Windows, macOS
Editing the application while the device runs.
Components are wired on the wiresheet; changes reach the device over SOX immediately and values are monitored live.
FiOC-32 · Coming soon
Monitoring at the panel door, networks on separate ports.
A 2.8" TFT display and rotary encoder allow values to be monitored and adjusted at the panel; two Ethernet and two RS-485 ports keep field and supervisory networks apart.
- BACnet/IP
- BACnet MS/TP
- Modbus TCP
- Modbus RTU
- MQTT
- Sedona / SOX
- Niagara N4
- BLE
Why Coselium
Our own R&D
Hardware, firmware and programming tools are developed by Cosel Elektronik’s own team.
One hardware family, two roles
FiOC-40 is a controller running a Sedona application on the device; FiO-40 is a remote I/O that needs no programming. Both have 40 points.
Workbench or Niagara N4
Applications are programmed with Coselium Workbench or from Niagara N4 with the cosel modules.
Licences when needed
Modbus TCP ↔ RTU gateway and BACnet IP ↔ MS/TP router functions are enabled by licence when required.
Product family
Controllers, remote I/O and the software that programs them. FiOC-40 and FiO-40 are in stock; FiOC-32 is coming soon.
Software
Coselium for Niagara N4
Programming and integration of Coselium devices from within Niagara N4
Available
Latest posts
Technical note
Backing up before maintenance and updates
Backing up the device before changing the program or updating the software lets you go back easily if something goes wrong. What gets backed up, and how is it restored?
Technical note
Software updates: step by step and what to watch
FiOC-40 software is updated from the web interface. This note gives a short checklist of what to watch before and after an update.
Technical note
Sending FiOC-40 data to a remote system with MQTT
To bring field values into a cloud dashboard, an energy monitoring tool or your own application, you can use MQTT. What does MQTT give you on FiOC-40?
Technical note
Reading the front-panel LEDs
The front-panel LEDs on FiOC-40 and FiO-40 show the state of every channel by colour. This note summarises what the colours mean, so that on site it is clear at a glance what is working and where a fault is.
Application story
Connecting fan-coil thermostats to the BMS: FiOC-40 BACnet router
BACnet thermostats talking over RS-485 can reach the BMS on Ethernet without a separate router. This note describes the router feature of FiOC-40.
Application story
When 40 points are not enough: expanding FiOC-40 with FiO-40
A large air handling unit or a panel serving several pieces of equipment can exceed 40 points. How to keep control on one device and add points with FiO-40 modules.
Application story
Adding points to an existing BMS without programming: FiO-40
You do not need a new controller to add a few sensors or outputs to a building. FiO-40 adds 40 points to the existing BMS without writing a program.
Technical note
Before you open a support request: where to find serial number, MAC and firmware version
Adding the device’s serial number, MAC address and firmware version to a support request speeds up the fix. This note shows where to find them on the device and in the web interface.
Technical note
Servicing from the Niagara station: users, clock and backups
Once a FiOC-40 is in a Niagara station, many service tasks are done in one place: users, clock, application backup and device information. This note summarises what is done where.
Technical note
What do outputs do when power returns or the network drops?
Which state a pump or valve is left in when power comes back or the BMS link drops should be known at design time. A summary of how Coselium devices behave.
Technical note
Reading energy, water and gas meters
Pulse-output meters can be connected straight to FiOC-40 and FiO-40 without an extra module. How to wire them and what to watch for.
Technical note
Two ways to connect a FiOC-40 to Niagara N4
For quick programming you can connect directly without a station; for continuous monitoring you bring the device into a Niagara station. This note summarises how the two paths differ and when each one is suitable.
Typical applications
Uses defined in the product datasheets.
Heating, cooling and ventilation
Control of equipment such as air handling units, pumps, boilers and chillers: the application on FiOC-40 decides which unit runs, when, and in what order.
FiOC-40Energy and alarm monitoring
Energy management, alarm and status monitoring; pulse-output meters on DI1–DI4.
FiOC-40Panel applications
Panel applications that need schedules and field logic.
FiOC-40Adding points to an existing BMS
Adding dry contacts, analogue sensors and universal points.
FiO-40Driving outputs
VAV dampers, analogue valves, relays and contactors.
FiO-40Retrofit
Integration without programming, using the ready Modbus and BACnet point list.
FiO-40
Typical setups
Eight typical setups Coselium devices are used in.
FiOC-40 as the panel controller
FiOC-40 · Coselium Workbench
Terminals · RS-485 · Ethernet · Bluetooth LE
Ethernet · RS-485 · Terminals
I/O expansion: FiOC-40 and FiO-40
FiOC-40 · FiO-40
RS-485 · Ethernet
RS-485 · Ethernet
Bringing MS/TP devices onto BACnet/IP: router
FiOC-40 · FiO-40
Ethernet · RS-485
With Niagara N4
Coselium for Niagara N4 · FiOC-40 · FiO-40
Ethernet · RS-485
Ethernet ↔ RS-485
Ethernet
Some of the projects using our products
The projects were carried out by our partner dealers.
Ceyhan State Hospital
Ceyhan, Adana
İzmir Bakırçay University Çiğli Training and Research Hospital
Çiğli, İzmir
İzmir Regional Court of Appeal
İzmir
Sinop Atatürk State Hospital
Sinop
Frequently asked questions
What is the difference between FiO-40 and FiOC-40?
Both come from the same hardware family and have 40 points (16 DI, 8 UI, 8 DO, 8 FIO). FiOC-40 is a controller that runs the control application on the device with Sedona; communication and point structure are set up per project. FiO-40 is a remote I/O that needs no programming and comes with a ready Modbus and BACnet point list.
How does it integrate with Niagara N4?
With the cosel modules: the FiOC-40 is reached through a direct device connection or a station driver. Kit Manager manages kits, Device Manager finds supported devices and Point Manager adds the selected points to the station. Devices can also connect through the standard BACnet/IP or Modbus TCP drivers.
Which software is used for programming?
FiOC-40 is programmed live over SOX with Coselium Workbench (Windows, macOS) or inside Niagara N4 with the cosel modules. FiO-40 needs no programming; it is configured from its local web interface or over BLE.
Which functions need a licence?
On FiO-40, basic Modbus RTU/TCP and BACnet/IP, MS/TP use needs no licence; a Level 1 licence enables the Modbus TCP ↔ RTU gateway and Level 2 adds the BACnet IP ↔ MS/TP router. On FiOC-40 the BACnet router is an optional add-on licence.
When will FiOC-32 be available?
FiOC-32 is in preparation; the release date will be announced once it is confirmed. You are welcome to contact us through the contact form for information.
Who installs and commissions the devices?
Design, installation and commissioning are carried out by our partner dealers. We provide our dealers with product and application training and technical support.
How can I become a dealer?
You can apply by choosing “Becoming a dealer” as the topic in the contact form or by writing to info@coselium.com.tr.
Where to buy
Coselium products are offered through our partner dealers and directly. Installation and commissioning are carried out by our partner dealers; we provide our dealers with product training and technical support.
